ONLY 4.7 MIL IMPRESSIONS!!
3450 sheets per hour 4/0
4600 sheets per hour in EPM 3/0
1725 sheets per hour 4/4
4600 sheets per hour 1/1 (monochrome)
Image resolution 812 dpi at 8 bit, writing system addressability: 812 dpi (virtual 2438 x 2438 dpi)
Line screens 175, 180, 180m, 190EPM, HMF200 lpi
Sheet size Maximum sheet size: 29.5 x 20.81 (In-house cutting: 29.527 x 20.866 in)
Minimum sheet size: 20.1 x 11.7 in for simplex; 20.1 x 13 in for duplex.
Image size 29.1 x 20.1 in maximum
Paper weight* Uncoated media: 50 lb text to 150 lb cover. Coated media: 60 lb text to 150 lb cover; Thickness 3-18 pt.
Thick substrate kit up to 24pt
Feeder Palette feeder 33.4 in of media. Drawer feeder: Two drawers, each with 11.8 in of media.
Stacker Main stacking tray with 33.4 in stack height supporting offset jogging
Print servers (DFE) HP SmartStream Production Pro Print Server
Press dimensions Length: 320 in; Width: 185 in; Height: 94 in
Press weight 24,250 lb
Cloud connectivity Via HP PrintOS
HP Indigo ElectroInks
Standard 4-color printing Cyan, magenta, yellow and black
5-color printing Use the 5th ink station
HP IndiChrome 6-color printing Cyan, magenta, yellow, black, orange and violet
HP IndiChrome Plus 7-color printing Cyan, magenta, yellow, black, orange, violet and green
Special effect inks White, light cyan, light magenta , light light black and fluorescent pink
HP IndiChrome off-press spot inks HP IndiChrome Ink Mixing Service for spot color creation using CMYK as well as orange, violet,
green, reflex blue, rhodamine red,
bright yellow and transparent
PANTONE® colors
Supports PANTONE PLUS®, PANTONE MATCHING SYSTEM®, and PANTONE Goe™
HP Professional PANTONE Emulation Technology using CMYK on-press; HP IndiChrome on-press; HP IndiChrome Plus on-press;
HP IndiChrome off-press for achieving up to 97% of the PANTONE® color range
Options
Print server (DFE) HP SmartStream Ultra Print Server
HP Indigo ElectroInk Primer Supports use of off-the-shelf papers
Expanded color capabilities 6 or 7 ink stations
Operator Control Station Proof jobs, control the press, DFE remote station
Auto Alert Agent Enables on-press quality alert system
Optimizer Automatic prioritization and management of the job queue
One Shot process kit Enables printing on synthetics, metalized and canvas using HP Indigo One Shot technology
HD Imaging System
Image resolution 812 dpi at 8 bit, writing system addressability: 1625 dpi (virtual 4876 x 4876 dp
